Ticket Vending Machine

Enhancing Accessibility & Security with Ticket Vending Machines (TVM)

Shellinfo Global’s latest Ticket Vending Machine (TVM) is an advanced self-service ticketing solution designed to enhance accessibility, security, and operational efficiency across modern transit and public venues. Built on a robust full-stack architecture, the TVM enables users to conveniently purchase tickets without assistance. Equipped with an intuitive touchscreen interface, secure card readers, and cash payment options, the system streamlines the ticket-buying experience while supporting both cashless and contactless transactions. Its user-centric design ensures ease of use for all passengers, including first-time users and individuals with accessibility needs.

Shellinfo Global’s TVMs are widely deployed across Metro railway stations, metro systems and entertainment venues, delivering reliable, secure, and fast ticket issuance while reducing queues and operational overheads. Enhancing accessibility and security, Shellinfo Global's latest Ticket Vending Machine (TVM) redefines the ticketing experience with Palm Vein authentication for seamless, touchless transactions. Designed for inclusivity, it features Braille support, an induction loop, and an audio jack, ensuring ease of use for visually and hearing- impaired passengers.

With support for QR, NFC, NCMC and EMV payments, Oppa TVM T5 offers a fast, secure, and convenient way to purchase tickets. Built for reliability and ease of maintenance, it seamlessly integrates with modern transit systems, making public transportation smarter and more accessible for all.

TVM


Ticket Vending Machine (TVM) - Uses, Features & Benefits

Caring

Ticket Vending Machine (TVM) - Uses

    Self-Service Ticket Issuance
    Single Journey Tickets (SJT) and Return Journey Tickets (RJT).

    Token Issuance
    Contactless tokens for one-time travel.

    Smart Card Recharge / Top-Up
    Stored value recharge and pass loading.

    Pass Purchase & Renewal
    Daily, weekly, monthly, and tourist passes.

    Fare Enquiry & Trip Planning
    Fare calculation based on source - destination selection.

    24x7 Unmanned Operations
    Continuous service during peak and non-peak hours.

    Multi-Modal Ticketing Support
    Metro, bus, suburban rail, and feeder services.

teamwork

Ticket Vending Machine (TVM) - Key Features

    User-Friendly Touchscreen Interface
    Intuitive UI with multilingual support.

    Multiple Payment Options
    Cash, UPI, QR, debit/credit cards, contactless/NFC.

    Fast Transaction Processing
    Quick ticket issuance with minimal wait time.

    Secure Payment & Fare Processing
    Encrypted transactions, EMV & PCI compliance (as applicable).

    Receipt & Ticket Printing
    Printed tickets with QR / barcode or magnetic / contactless media.

    Smart Card Reader / Token Dispenser
    Supports NCMC, closed-loop cards, and contactless tokens.

    Remote Monitoring & Diagnostics
    Centralized health monitoring and fault alerts.

    Configurable Fare Products
    Zone-based, distance-based, time-based fare rules.

    Rugged & Vandal-Resistant Design
    Suitable for high-footfall public environments.

teamwork

Ticket Vending Machine (TVM) -
Major Benefits

    Reduced Queue at Ticket Counters
    Minimizes dependency on manned Ticket Office Machines (TOMs).

    Improved Passenger Convenience
    Faster, simpler, and self-service ticket purchasing.

    24x7 Availability
    Always-on service without staffing constraints.

    Lower Operational Costs
    Reduces manpower and cash-handling expenses.

    Higher Throughput During Peak Hours
    Handles large passenger volumes efficiently.

    Accurate & Transparent Fare Collection
    Eliminates human errors and ensures correct fare application.

    Supports Cashless & Digital Payments
    Aligns with smart city and digital India initiatives.



Core Features

Convenience

Convenience

  • Compact design, 60% less volume than traditional machine, save space and convenience for layout
  • Internal maintenance panel has ticket adding and clearing accounts settling, fault diagnosis, parameter configuration functions
  • Compact size and modular design. Modules can be pulled out from guide rail for fast maintenance

Interaction

Interaction

  • Large touch screen with multi-touch graphical operation experience and humanized interactive interface
  • Support advertising when no patron operates
  • Support third party value-added services

Reliability

Reliability

  • Tempered glass panel resisting to scratch and impact
  • Advanced painting process, artistic outlook with smooth edge

Efficiency

Efficiency

  • Flexible hybrid recycling change solution, large recycling change capacity design
  • High performance scanner which has 3600 all orientation scanning with high speed, making ticket purchasing more convenient



Optional Modules


Fully Customizable Design

Fully Customizable Design

Configure the TVM with a variety of coin, banknote, ticket handling, and recognition modules to match specific transit system needs.

Adaptable

Adaptable to Any Environment

Available in multiple configurations for indoor and outdoor use, with customizable display, interface, and accessibility features.



Specifications

m n
TECHNICAL DATA   OPPA TVM T5
Type   Cashless or Cash (with optional modules)

Dimension Height - 1650 mm
Width – 424 mm
Depth – 525 mm
Height from ground to TVM Bend (Reader) – 560 mm
Weight 180 Kgs
IP Rating IP 52
Card Reader Shellinfo Oppa Reader supports NFC, QR, Type A/B/C Cards, NCMC & EMV Cards
Validation Modes Palm Vein, EMV, QR Code and Closed Loop Cards
AI Models Deep Seek for Interactive Voice Assistance
ECU
    Processor Arm based SoC, Octa-core CPU, 2.2 Ghz - 4 x Cortex A78 (Cores) & 4 x Cortex A55 (Cores)
    NPU 4.8 TOPS Neural Network performance
    GPU Arm Mali – G57, 880 MHz
    Memory (RAM) 8 GB (onboard) LPDDR4, 4000 MT/s
    Flash 32 GB eMMC Flash and 8 MB SPI NOR Flash for board information
    I/O Interface 2 x USB 2.0, 1 x USB 3.0, 3 x RS232, 1 x HDMI 2.0, 4K60, 1 x Dual Channel LVDS, 2 x 10/100/1000 Mbps, 3 x Serial Ports, 10 x GPIO Ports
    Operating System Android OS 11 or above
Display
    Screen Type Touch Screen PCT touch (10 points)
    Screen Size 21.5 inch
    Viewing angle Horizontal:89°, Vertical:89°
Power Consumption Input Voltage - 170~264VAC
Output Voltage - DC 24V
Audio Speaker Amplifier
Payment Terminal Supports multiple COTS POS terminals
Operational Temperature -30°C ~ +70°C
Working humidity 20% ~ 90% RH (non-condensing)
Printer Thermal Printer
MCBF 25000
MCBJ 50000
Optional Modules Coin Modules: Single Coin, Multi Coin, Multi-recycler Banknote Modules: Cash Acceptor, Cash Recycler, Cash Dispenser Ticket Dispensing Modules: Card Issue, Token Issue, Paper Issue Recognition: Facial, Finger Vein
